Product Description
- What project are you undertaking?
- What are you cutting? Is it hard or soft wood? Is it stainless steel, fiberglass, MDF, acrylic, or aluminum?
- In case you’re new to CNC routing and you want a multi-purpose bit, go for two-flute spiral bits since they cut a wide range of materials, including plastics, aluminum, foam, and wood.
Genmitsu MC40A
40pcs End Mills CNC Router Bits
- 10 x Spiral Flat Nose End Mills, 2-Flute
- 10 x Spiral Ball Nose End Mills, 2-Flute
- 10 x Nano Blue Coating End Mills (different cutting diameter: 0.8mm, 1.0mm, 1.2mm, 1.4mm, 1.6mm, 1.8mm, 2.0mm, 2.2mm, 2.5mm, 3.0mm)
- 10 x Titanium Coating End Mills (different cutting diameter: 0.8mm, 1.0mm, 1.2mm, 1.4mm, 1.6mm, 1.8mm, 2.0mm, 2.2mm, 2.5mm, 3.0mm)
- Material: Tungsten Carbide Steel Alloy
- Surface : Nano Blue Coating/Titanium Coating
- Shank Diameter: 1/8'' (3.175mm)
- Cutting Diameter: 0.8-3mm, 3.175mmc
- Cutting Length: 17mm
- Overall Length: 38mm
Cost-Effective Set
The MC40A end mill set includes 4 type bits: spiral flat nose bits, ball nose bits, Nano Blue Coat end mills and Titanium Coat end mils. It's a very cost-effective set to meet your all needs in engraving work.
Wide Application
Widely used in various materials including plastics, aluminum, circuit board, wood, as well as other precision parts processing. They are compatible with most desktop CNC machines, such as the Genmitsu 3018 Series, as well as other industrial CNC machines.
High Quality
Its Nano Blue Coating /Titanium Coating with high hardness and heat resistance enables the tool's cutting edge to retain crucial sharpness and lubricity. This provides longevity and produces cutting results of the highest quality.
EM03A
|
70V30
|
EM10A
|
MC50A
|
MC30A
|
MC30B
|
|
|---|---|---|---|---|---|---|
|
|
|
|
|
|||
| Customer Reviews |
44
|
621
|
250
|
209
|
12
|
6
|
| Type | Tapered Ball Nose & V-Shape End Mill | V-Shape End Mill | Tapered Ball Nose & Single Flute Spiral End Mill, Flat Bottom Carbide Engraving Bit | 2-Flute Flat/Ball Nose End Mill, Corn-shaped End Mill, PCB Drill Bit, V-Groove Router Bit, 2-Flute Straight Router Bit | O Flute & 2-Flute Ball Nose, Corn-shaped End Mill | Corn-shaped & 2-Flute Flat Nose End Mill, V-Groove Engraving Bit |
| Surface | Nano Blue Coating | Nano Blue Coating | Nano Blue Coating | Nano Blue Coating & Titanium Coating | Nano Blue Coating & Titanium Coating | Nano Blue Coating & Titanium Coating |
| Shank Diameter | 1/8''(3.175mm) | 1/8''(3.175mm) | 1/8''(3.175mm) | 1/8''(3.175mm) | 1/8''(3.175mm) | 1/8''(3.175mm) |
| Cutting Diameter/Radius | R0.1mm, D0.2mm, D0.25mm | / | / | 1-3.175mm, 1.1-2.0mm | 0.8mm, 3.175mm | 0.1mm, 3.175mm |
| Quantity | 3 | 10 | 10 | 50 | 30 | 30 |
TB04A
|
PD30A
|
RB03A
|
VG05A
|
RB10A
|
ER11
|
|
|---|---|---|---|---|---|---|
|
|
||||||
| Customer Reviews |
250
|
701
|
152
|
248
|
— |
468
|
| Type | 2-Flute Tapered Ball Nose End Mill | PCB Drill Bit | 3-Flute Spoilboard Surfacing Router Bit | V-Groove Router Bit | HSS Router Bit | ER11 Collet |
| Surface | Nano Blue Coating | / | / | / | Titanium Coating | / |
| Shank Diameter | 1/8''(3.175mm) | 1/8''(3.175mm) | 1/4" (6.35mm) | 1/4" (6.35mm) | 1/8''(3.175mm) | 1.0mm-7.0mm |
| Cutting Diameter/Radius | R0.25-1.0 | 0.1-3.0mm | 24mm | 16-32mm | 3.175-9.5mm | / |
| Quantity | 4 | 30 | 3 | 5 | 10 | 15 |
