Red Lion RL-SPRK Series Selecting the Right Pump for Your SystemFranklin Electric - Little Giant
  • Red Lion RL-SPRK200 230 Volt, 2 HP, 76 GPM Cast Iron Sprinkler/Irrigation Pump with Thermoplastic Impeller, Red, 97102001
  • To view this video, download
  • 4 VIDEOS

Red Lion RL-SPRK200 230 Volt, 2 HP, 76 GPM Cast Iron Sprinkler/Irrigation Pump with Thermoplastic Impeller, Red, 97102001

4.1 out of 5 stars 302 ratings
To see product details, add this item to your cart. You can always remove it later.

Purchase options and add-ons

Brand Red Lion
Colour Red
Material Cast Iron
Style 2 HP, Thermoplastic Impeller, 230 Volt only
Product Dimensions 47.2L x 29W x 25.9H Centimetres
Power source Corded Electric
Item weight 28.58 kg
Maximum flow rate 76 Gallons Per Minute
Maximum lifting height 5 Feet
Voltage 230 Volts

About this item

  • BUILT TO LAST: Rugged cast iron pump housing and glass-filled thermoplastic impeller for well water and lake water
  • MOTOR SPECIFICATIONS: 230 VOLTS, 10.9 running Amps, Capacitor-run PSC design, 7332 locked rotor watts, thermally protected, CSA listed in the US and Canada
  • ONE-TIME PRIMING: No additional priming is required after initial fill; follow the priming instructions in the owner's manual
  • UP TO 76 GPM at 10 PSI: 64 GPM at 30 PSI - can handle up to 21 sprinkler heads with 1/2-inch fittings or 10 sprinkler heads with 3/4-inch fittings in each zone
  • SPECIFICATIONS: 2.0 HP, 230 Volts, 2-inch Female NPT threaded intake; 1.5-inch Female NPT threaded discharge, Max pressure 49 PSI; pump cannot be used with 115 Volt power source

What do customers buy after viewing this item?

Page 1 of 1 Start again
Previous set of slides

  1. Bestselling | Highest rated | Lowest price

    in this set of products
Next set of slides

From the manufacturer

RL-SPRK200 A+ Content Main Image 970x600
RL-SPRK200 A+ Content Callout 970x600

RL-SPRK200 (97102001) Technical Specifications

Motor 2.0 hp open, drip-proof, thermally protected motor
Voltage 230-volt; voltage of pump must match voltage of power source or performance will be far lower than desired
Amperage 10.9 running Amps @ 230 V
Wattage 7332 Watts
Intake 2" FNPT
Discharge 1-1/2" FNPT
Performance @ 10 psi (5' lift) 76 gpm
Performance @ 20 psi (5' lift) 75 gpm
Performance @ 30 psi (5' lift) 65 gpm
Performance @ 40 psi (5' lift) 47 gpm
Number of sprinklers supported 21 sprinkler heads with 1/2" fittings @ 30 psi; 10 sprinkler heads with 3/4" fittings @ 30 psi
Maximum pressure 49 psi
Materials Cast iron casing; thermoplastic impeller
Sprinkler Pumps Selection and Installation Tips - 4 970x600

Product Selection Tips:

The easiest way to select the proper pump for the job is to determine how many sprinkler heads and what size pipe is used. If 1/2" pipe is used, the formula is GPH at 30 PSI divided by 3. If 3/4" pipe is used, the formula is GPH at 30 PSI divided by 6. We have done the calculations for you and the information can be found in both the technical specifications and the pump comparison chart found on this page.

Installation Tips:

This pump is rated 4 out of 5 stars in level of difficulty (5 being most difficult). Electrical wiring is required along with precise measurements for cutting the piping. This pump is designed to work with a pump start relay and a timer (not included.) We strongly recommend hiring a sprinkler pump installer or contractor with sprinkler installation experience for this installation.

  • This pump is DUAL VOLTAGE which means it will work with both 115 Volt and 230 Volt power sources. The voltage selection indicator on the pump MUST MATCH the power source. The pump comes PRE-SET for 230 Volt operation. To use the pump for 115 Volt installation, the voltage indicator on the pump must be changed to 115 Volts. Instructions for changing the voltage are in the Owner's Manual. A small motor cover is located on the back end of the pump's motor and must be removed with a screwdriver. For the 1 HP model, once the cover is removed, insert a flat head screwdriver in the voltage change indicator and rotated counter clockwise so it read 115 and replace the motor cover. (See Owner's Manual for illustration.)
  • USE PTFE tape on all pipe thread and ensure the the suction and discharge lines are completely AIRTIGHT otherwise the pump will lose prime and will be extremely noisy (called cavitation).
  • PRIME the pump! Remove the priming port plug at the top of the unit. Open the discharge valves on the discharge side of the pump. Fill the pump with water through the priming port. Allow trapped air to escape for a few minutes, then add more water until the pump and line is full. Replace the priming port plug and tighten with a wrench.
  • A CHECK VALVE (not included) should be installed on the discharge line to keep the pump primed and a STRAINER should be used on the intake line to keep debris from entering the pump.
  • Additional instructions, safety tips, and troubleshooting tips are found in the Owner's Manual.

Red Lion RL-SPRK100, 97101001
Red Lion RL-SPRK150, 97101501
Red Lion RL-SPRK150-BR, 9710502
Red Lion RL-SPRK200, 97102001
Red Lion RL-SPRK-200-BR, 97102002
Customer Reviews
3.7 out of 5 stars 70
4.1 out of 5 stars 505
4.0 out of 5 stars 30
4.1 out of 5 stars 302
4.2 out of 5 stars 44
Horsepower 1.0 hp 1.5 hp 1.5 hp 2.0 hp 2.0 hp
Impeller material Thermoplastic Thermoplastic Brass Thermoplastic Brass
Voltage 115/230 Volts 115/230 Volts 115/230 Volts 230 Volts 230 Volts
Amperage 14 A @ 115 V; 7A @ 230 V 18.6 A @ 115 V; 9.3A @ 230 V 18.6 A @ 115 V; 9.3 A @ 230 V 10.9 A @ 230 V 10.9 A @ 230 V
Intake - 2" FNPT ✓ ✓ ✓ ✓ ✓
Discharge - 1.5" FNPT ✓ ✓ ✓ ✓ ✓
Flow rate at 30 psi (5' lift) 38 gpm 44 gpm 44 gpm 65 gpm 64 gpm
Maximum pressure 45 psi 44 psi 41 psi 49 psi 47 psi
Max sprinklers (1/2" fittings) 12 sprinkler heads per zone 14 sprinkler heads per zone 14 sprinkler heads per zone 21 sprinkler heads per zone 21 sprinkler heads per zone
Max sprinklers (3/4" fittings) 6 sprinkler heads per zone 7 sprinkler heads per zone 7 sprinkler heads per zone 10 sprinkler heads per zone 10 sprinkler heads per zone

Product information

Technical Details

Manufacturer ‎Franklin Electric Canada, Inc.
Place of Business ‎FORT WAYNE, IN, 46809 US
Part Number ‎97102001
Product Dimensions ‎55.5 x 29.01 x 25.91 cm; 28.58 kg
Item model number ‎97102001
Is discontinued by manufacturer ‎No
Size ‎2 Hp
Colour ‎Red
Style ‎2 HP, Thermoplastic Impeller, 230 Volt only
Material ‎Cast Iron
Pattern ‎Sprinkler Pump
Power Source ‎Corded Electric
Voltage ‎230 Volts
Wattage ‎7332 watts
Horsepower ‎2
Item Package Quantity ‎1
Flow Rate ‎76 Gallons Per Minute
Measurement System ‎Imperial
Usage ‎Amateur, Professional
Included Components ‎Pump with thermoplastic impeller, Installation manual
Batteries Included? ‎No
Batteries Required? ‎No
Warranty Description ‎2 year manufacturer
Item Weight ‎28.6 kg
Country of origin ‎China

Additional Information

ASIN B07HFDP7H3
Customer Reviews
4.1 out of 5 stars 302 ratings

4.1 out of 5 stars
鶹 Rank
Date First Available July 3 2018

Feedback

Red Lion RL-SPRK200 230 Volt, 2 HP, 76 GPM Cast Iron Sprinkler/Irrigation Pump with Thermoplastic Impeller, Red, 97102001

Found a lower price? Let us know. Although we can't match every price reported, we'll use your feedback to ensure that our prices remain competitive.

Where did you see a lower price?
/
/
/
/
Please sign in to provide feedback.

From the brand

Previous page

  2. To our valued Canadian customers:

    Canada and the Red Lion brand are closely connected. The Red Lion brand was created by Canadians in Winnipeg, Manitoba, specifically for homeowners. The brand is registered to Franklin Electric Canada, Inc., and all of our products supplied to 鶹.ca are fulfilled by Canadians through our Canadian distribution center located in Bolton, Ontario. We appreciate your continued support.

  3. About Us

    Backed by the heritage of a global leader in the development and manufacturing of systems and components that move water, the Red Lion brand remains at the forefront of product innovation by listening to its customers, adapting to the market, and continuing to invest in research and development. This innovative product portfolio is supported by unparalleled service to provide you with current solutions to your water pumping challenges.

  4. Red Lion RJS-75-PREM 3/4 HP, 16 GPM, 115/230 Volt, Premium Cast Iron Shallow Well Jet Pump, Red, ...
    Red Lion RL-SWJ50 1/2 HP, 12.6 GPM Dual Voltage (115/230 Volts) Cast Iron Shallow Well Jet Pump, ...
    Red Lion PumpWorks PWJET50 1/2 HP, 7 GPM, Dual Voltage (115/230 Volts) Cast Iron Shallow Well Jet...
    Red Lion RJS-75SS 115/230 Volt, 3/4 HP, 12.8 GPM Stainless Steel Shallow Well Jet Pump, Red, 9708...

    Shop Shallow Well Jet Pumps

    Visit the store

  5. Red Lion RJC-100 115/230 Volt, 1 HP 20 GPM Premium Convertible (Shallow or Deep Well) Jet Pump, R...
    Red Lion RJC-50-PREM 115/230 Volt, 1/2 HP 14.2 GPM Premium Convertible (Shallow or Deep Well) Jet...
    Red Lion PumpWorks PW-CJ75 115/230 Volt, 3/4 HP, 8.1 GPM Convertible (Shallow or Deep Well) Jet P...
    Red Lion PumpWorks PW-CJ50 115/230 Volt, 1/2 HP, 7.9 GPM Convertible (Shallow or Deep Well) Jet P...

    Shop Convertible Jet Pumps

    Visit the store

  6. Red Lion RL12G05-3W2V Submersible Deep Well Pump with Control Box 1/2 HP, 12 GPM, 3-Wire, 230 Vol...
    Red Lion RL12G05-2W2V 4-inch Submersible Deep Well Pump, 1/2 HP, 12 GPM, 2-Wire, 230 Volt, Steel,...
    Red Lion RLCB05-230 1/2-HP 230-Volt VMC Control Box for Submersible Well Pump, Grey, 640189
    Red Lion RLCB15-230 1.5-HP 230-Volt VMC Control Box for Submersible Well Pump, Gray, 640222

    Shop Deep Well Products

    Visit the store

  7. Red Lion RJSE-75SS 115 Volt, 3/4 HP, 11 GPM Stainless Steel Sprinkler Utility Pump with 8-ft. Cor...
    Red Lion RJSE-50 115 Volt, 1/2 HP, 12.8 GPM Portable Sprinkler Pump with 8-Ft. Cord, Red, 614430
    Red Lion RL-SPRK150 115/230 Volt, 1.5 HP, 71 GPM Cast Iron Sprinkler/Irrigation Pump with Thermop...
    Red Lion RL-SPRK200 230 Volt, 2 HP, 76 GPM Cast Iron Sprinkler/Irrigation Pump with Thermoplastic...

    Shop Lawn & Irrigation Pumps

    Visit the store

  8. Red Lion RL-SPS33 1/3 HP, 115-Volt, 3200 GPH Under-Sink Sump Pump System with 6 Gallon Basin, Red...
    Red Lion RL-MP25 115 Volt, 1/4 HP, 2200 GPH Manual Thermoplastic Submersible Utility Pump, 8-Ft. ...
    Red Lion RL-MP16 115 Volt, 1/6 HP, 1300 GPH Manual Thermoplastic Submersible Utility Pump, 8-Ft. ...
    Red Lion RL-MP25A 115 Volt, 1/4 HP 2200 GPH Automatic Thermoplastic Submersible Utility Pump, 10-...

    Shop Utility Pumps

    Visit the store

  9. Red Lion RL-SC50T 115-Volt, 1/2 HP, 4300 GPH Cast Iron Sump Pump with Tethered Float Switch, 10-F...
    Red Lion RL-SP33V 115-Volt, 1/3 HP, 3200 GPH Aluminum and Thermoplastic Sump Pump with Vertical S...
    Red Lion RL-SS50V 115 Volt, 1/2 HP, 3450 GPH Premium Submersible Stainless Steel Sump Pump with V...
    Red Lion RL75CSS 115 Volt, 3/4 HP 4500 GPH Stainless Steel Sump Pump with Snap-Action Switch, Ste...

    Shop Sump Pumps

    Visit the store

  10. Red Lion RL-WC50TA 115 Volt, 1/2 HP, 5600 GPH Cast Iron Sewage Pump with Tethered Switch and 10-F...
    Red Lion RL-WCS50TA 115 Volt, 1/2 HP, 5600 GPH Automatic Sewage System with Cast Iron Pump and 18...
    Red Lion RL-S50 115/230 Volt, 1/2 HP, 2940 GPH Self Priming Cast Iron Surface Effluent Pump, Red,...
    Red Lion RL50WA 115 Volt, 1/2 HP, 7200 GPH Sewage Pump with Piggyback Tethered Switch and 20-Ft. ...

    Shop Sewage and Effluent Pumps

    Visit the store

  11. Do you support your products?

    Yes, please see below.

    30 Day Return Policy

    For items purchased within 30 days, please refer to 鶹's 30-day return policy.

    After 30 Days

    Please check your invoice or order. If the seller indicates a company other than 鶹.com.ca, Inc. please contact the seller directly for more information. If 鶹.com.ca, Inc. is the seller, your product is covered by the terms outlined in our manual. Please refer to your owner's manual for more information. Our staff are also able to assist with troubleshooting or installation assistance.

  12. Brand Focus 362 x 453 trimmed
Next page

Product description

The Red Lion RL-SPRK200 230 Volt, 2 HP sprinkler irrigation pump is idea for both residential and commercial lawn and turn sprinkling systems. This pump features a rugged cast iron casing, high efficiency thermoplastic impeller and diffuser and is to easy to prime to 25-ft - no additional priming is required after the initial fill. This pump is not designed for 115 Volts and does not come with a cord. The pump must be wired into a 230 Volt power source. If pump is not performing to specifications, ensure pump is connected to 230 Volt power source.
