| Manufacturer | Zhangzhou Eastern Intelligent Meter Co., Ltd |
|---|---|
| Place of Business | Zhangzhou, Fujian 363000,CN |
| Parcel Dimensions | 26.7 x 26.29 x 11.4 cm; 1.38 kg |
| Batteries | 2 9V batteries required. |
| Is discontinued by manufacturer | No |
| Colour | Black |
| Material | ABS |
| Item Package Quantity | 1 |
| Batteries Included? | No |
| Batteries Required? | Yes |
| Battery Cell Type | Zinc Carbon |
| Battery Description | 9V battery |
| Item Weight | 1.38 kg |
Image Unavailable
Colour:
-
-
-
- To view this video, download
-
-
-
-
-
-
-
2 VIDEOS -
allsun Pro Ultrasonic Leak Detector& Transmitter Automotive Noise Finder Electronic Stethoscope Machine Noise Monitor 36-44KHz Air Gas Water Dust Leak Pressure Vacuum Diagnose Tool
Purchase options and add-ons
- ¡¾ULTRASONIC TECHNOLOGY¡¿Ultrasonic Leak Detector& Transmitter uses ultrasonic sensing technology and features small size and light weight. It is reliable and easy to use and is a practical,portable tool.
- ¡¾WORKING PRINCEPLE¡¿Automotive Noise Finder,turbulence created by gas or air forced through a small office generates ultrasoncic sound. Ultrasonic sound occurs when the atmosphere leaks into a vacuum vessel or when a pressure vessel leaks to the outside atmosphere.
- ¡¾FREQUENCY¡¿Electronic Stethoscope, ultrasonic sound's frequency is related to the size of the orifice which ultrasonic sound passes through, but usually the frequency is about 40kHz. Frequency Response: 36kHz-44kHz.
- ¡¾WIDELY APPLICATION¡¿Machine Noise Monitor, machine Abnormal Noise Detect; By using this instrument, you can quickly and accurately locate leaks in any pressure and vacuum system. Suitable for detecting cracks of pipes, valves,oil tank and other sealed compartment.
- ¡¾WHAT YOU GET¡¿Air leak detector package includes, Leak detector; Ultrasonic probe; Ultrasonic microphone; Ultrasonic TRANSMITTER; Extension tube; Probe tips,70mm and 290mm; Headphone(with volume adjuster).
Frequently bought together

Videos for similar products
From the brand
-
-
-
Based on ISO9001 International Quality System, most products are exported to Europe and USA with approvals of CE, UL, GS, CMC.
We have wide product range to meet different purchased requirements. The main products contain Digital Multimeters, Metal Detectors, Ultrasonic Measures, Infrared testers.One-stop style make purchase easy,and greatly reduce purchase cost,shorten purchase time and assure purchase quality control.
-
Automotive Tester
-
Metal Detector
-
DIY Tool
Product Description
Very thanks for choosing allsun EM2268 Ultrasonic Leak Detector. The main products from allsun contain Car Data Saver,Multi-meter,Digital Multimeters,Digital Clamp meter,Metal Detectors,Distance Measures,Infrared Thermometer,Voltage, Battery Tester,Digital Scale and multifunction sensor all of which have an advantage in domestic and overseas markets.
If you are now looking for a Ultrasonic Leak Detector, exactly, just choose it!
INTRODUCTION: (Ultrasonic Leak Detector)
Princeple
Turbulence created by gas or air forced through a small office generates ultrasoncic sound. Ultrasonic sound occurs when the atmosphere leaks into a vacuum vessel or when a pressure vessel leaks to the outside atmosphere. Ultrasonic sound's frequecy is related to the size of the orifice which ultrasonic sound passes through, but usually the frequency is about 40kHz. Ultrasonic sound is very directional, this directionality is used to pinpoint the origin of the ultrasonic sound, the leak point.
Ultrasonic Leak Detector
This instrument uses ultrasonic sensing technology and features small size and light weight.It is reliable and easy to use and is a practical,portable tool.
Ultrasonic Transmitter
This ultrsonic transmitter generates supersonic waves whose frequency is about 40kHz. By using the ultrasonic transmitter and the leak detector together,you can check tightness of non-pressurized compartments.
Technical Data
Signal Indicator: LED-array,headphone
Frequency Response: 36kHz-44kHz
Operating Environment: temperature:0-50 degree C
relative humidity: less than or equal to 85%
Battery: 9V battery,6F22 or equivalent(exclude)
Size: Leak Detector: 215x50x30 mm
Ultrasonic Transmitter: 103x60x24 mm
Weight: Leak Detector:about 162g
Ultrasonic Transmitter:about 90g
Product information
Technical Details
Additional Information
| ASIN | B07B8GFCDL |
|---|---|
| Customer Reviews |
3.3 out of 5 stars |
| Âé¶¹Çø Rank |
|
| Date First Available | March 10 2018 |
