Gikfun USB Cable Tester Board USB Cable Checker Data Wire Charging Test Data Line for Type-C Micro AB Lightning RJ45 Connector GK1030C

Brand: Gikfun

10 ratings

Lowest price in 30 days

To see product details, add this item to your cart. You can always remove it later.

Up to 6% off if you qualify qualifying items | Terms

Purchase options and add-ons

Brand	Gikfun
UPC	739807423452
Manufacturer	Gikfun

About this item

Interface Type Identification: This tester is a professional tool designed to quickly identify USB cable types (USB 3.2/USB 3.1/USB 3.0/Type-C/Micro-AB/Lightning/RJ45 connector)
RJ45 Connector Testing:Supports 8-core network cable continuity testing (displays the status of each wire via indicators).Compatible with 100Mbps/1000Mbps network testing.
Convenient and practical: The product features a portable design, compact size, and is easy to carry and use.Connect the tester to a DC 5V-12V power source.
LED indicator lights: Test results are displayed through 24 LED indicators, with each pin corresponding to an LED light.
Multi-functional and practical:It is suitable for Cable Performance Testing, scenarios such as electronic repair, device debugging, and cable procurement.

› See more product details

�� Report an issue with this product

Product details

Parcel Dimensions ‏ : ‎ 9.6 x 6.91 x 3.2 cm; 59 g
Date First Available ‏ : ‎ March 28 2025
Manufacturer ‏ : ‎ Gikfun
Place of Business ‏ : ‎ Gikfun
ASIN ‏ : ‎ B0F1D5NDCV
Manufacturer reference ‏ : ‎ GK1030
Country of origin ‏ : ‎ China
�鶹�� Rank: #87,933 in Tools & Home Improvement (See Top 100 in Tools & Home Improvement)
- #163 in Multi Testers
Customer Reviews:
10 ratings

This item: Gikfun USB Cable Tester Board USB Cable Checker Data Wire Charging Test Data Line for Type-C Micro AB Lightning RJ45 Connector GK1030C

$20.39

Get it by Tuesday, Nov 18

In Stock

Sold by Gikfun_Official_Store and ships from �鶹�� Fulfillment.

Treedix USB Cable Data Line Test Board with Acrylic Case, Checker, Wire - Type-C, Micro, A, B

$40.60

Get it Nov 18 - 20

In Stock

Ships from and sold by Canavax.

Total price:��$00

To see our price, add these items to your cart.

Try again!

Details

Added to Cart

These items are shipped from and sold by different sellers.

Show details Hide details

Choose items to buy together.

Brief content visible, double tap to read full content.

Full content visible, double tap to read brief content.

Videos for similar products

Product Description

Clean and Organized Drawer

After testing and organizing your USB cables, you'll find it a breeze to locate the one you need.

Interface Type Identification:

This tester is a professional tool designed to quickly identify USB cable types (USB 3.2/USB 3.1/USB 3.0/Type-C/Micro-AB/Lightning/RJ45 connector)

How to Test USB Cables?

First, toggle the switch to your chosen power supply mode. Next, insert the USB cable into the corresponding USB port, and the LED indicators will light up, indicating the connection status and functionality of the USB cable.

USB Cable Test Board

Due to the diverse array of USB cable configurations , the provided visual schematic depicts a subset of common variants. However, the standardized diagnostic protocol for verifying USB data cable integrity remains universally applicable.

The Reference of Different Cables to Different Lights

Test Example 1:

The USB cable tester operates at a DC voltage range of 5V to 12V. Upon power connection, the power indicator LED (red) on the PCB illuminates.

Test Example 2:

Cable tester connected to a Lightning cable. Under normal cable conditions, 5 LEDs light up: a power group (VBUS and GND), a data reception group (D+ and D-), and either CC1 or CC2 indicating the orientation (front/back side).

Test Example 3:

The USB cable tester, when connected to a Micro-AB USB cable, illuminates four LEDs under normal operation:

Power pair: VBUS & GND LEDs
Data transmission pair: D+ & D- LEDs The device complies with USB 2.0 specifications.

Test Example 4:

The USB cable tester, when connected to an RJ45-terminated network cable, illuminates all 8 "Network" LEDs on the PCB if the cable is crimped according to T568A/B wiring standards.

Test Example 5:

The USB cable tester, when connected to a dual Type-C USB 3.2 cable, illuminates 22 LEDs. The cable supports high-speed video and audio transmission. Please note that only one set of the two D+/D- signal pairs can be activated simultaneously at a time

Test Example 6:

When the USB cable tester is powered normally (with the power LED illuminated) but exhibits an insufficient number of activated LEDs upon cable insertion, this indicates an internal open circuit or physical damage at the cable connector interface.
