| Input voltage | 240 Volts |
|---|---|
| Mounting type | Ceiling Mount |
| Material | silk fabric |
| Model name | HCS628-16BT-4CH-CA |
| Speaker type | Surround Sound |
| Special feature | Bluetooth, Multi Room Audio, Auxiliary, USB |
| Recommended uses for product | For Home Theater, Smartphones or Tablets, Televisions |
| Compatible devices | Smartphone |
| Subwoofer diameter | 6.5 Inches |
| Surround sound channel configuration | 4.0 |
| Colour | White |
| Included components | Ceiling Speakers x4, Instruction manual x2, Speakers Wire x4, in wall amplifier x1 |
| Product Dimensions | 8D x 19W x 19H Centimetres |
| Impedance | 8 Ohm |
| Is waterproof | False |
| Warranty type | Limited |
| Maximum range | 3E+1 Feet |
| Number of Items | 4 |
| Control method | Voice |
| Wireless communication technology | Bluetooth |
| Speaker size | 6.5 Inches |
| Power source | Corded Electric |
| Manufacturer | Herdio |
| Place of Business | Herdio |
| Item model number | SZJW-628-16BT-4CH-AU |
| ASIN | B0B1C7XWVB |
Product information
Additional Information
| 鶹 Rank |
|
|---|
Feedback
Videos for similar products
Product Description
Connection Diagram
Home Ceiling & in-wall Speakers And In Wall Bluetooth Amplifier Receiver
Herdio is commitment to high-quality products in the field of ceiling speaker systems, has made it a trusted name in home audio speakers and entertainment systems. The Heridio In wall Flush Mount speakers kit is built with carefully selected components and rigorous design to deliver exceptional value and performance. Each speaker features a high-compliance polymer tweeter that delivers full, rich sound without cluttering floor space. Independent 4 channel Advanced 5.0 Technology wall mount plate audio control amplifier receiver system allows for wireless music streaming ability and doubles as a sound processing digital amplifier. This combination provides the utmost flexibility in terms of configuration and suitability to different types of audio tastes.
Flush Mount Design
Compact flush mount design for simple easy installation in-wall / in-ceiling, for in home use, office, on any flat surface for a clean look & achieve wide range sound performance without compromise.
Removable & Paintable Grille
Simple to install and paintable to match existing wall color, the in-Ceiling Speakers is an ideal way to add superior quality sound to a room without taking up any additional space.
Spring Loaded Speaker Terminal
Spring-loaded speaker terminals allow for easier installation or removal, quick and easy installation without the need for expensive professional installation.
Superior Sound Quality
Herdio ceiling speakers have built-in high definition digital stereo effects and impressive enough bass effects. You will be able to stream audio from your smart devices and enjoy the clear, pure, high-quality syllables.
Flash Drive Reader & Device Charge Port
The in wall amplifier features USB flash memory reader for media playback which also doubles as charging port for your devices.
Volume Knob
Switching on/off and adjusting the volume is more convenient and quicker: After connecting to a smart device to play music, turn the Volume Knob to switch on/off, and then turn the Volume Knob to adjust the volume.
Microphone Paging & Speaker Control
Take control of your audio system. With this easy to use in-wall plate amplifier you can control the volume of your sound as well as have multiple inputs that connect to your stereo system/speakers. Microphone paging is also easy to do. Suitable for making announcements or paging someone in the office.
2 Ways to Connect Power
The Wall Amplifier Can Be Hard-Wired or Powered via Included Power
1、Plug the adapter in the box directly into the power jack on the front of the panel, and connect the other end to the 110-220V power supply.
2、There are two wires in the 16BT box, 2-pin wire and 3-pin wire. The 2 colors are connected to the DC12V power supply, and the 3 colors are used for AUX connection.
Ceiling Speakers Specs:
- Power Output: 600Watt MAX (2 Pairs) (150 Watts Each Speaker)
- Sensitivity: 89dB
- Impedance: 8Ohm
- Frequency Response: 60-20KHZ
- Cut-Out Diameter: 8 Inch(20.5 CM)
- Mounting Depth: 3.15 inches(8 CM)
In Wall Amplifier Specs:
- Power Output: 100 Watt Peak, 40 Watt RMS x 4 Ch. @ 4 Ohm
- Advanced Technology Compatible with Bluetooth Version: 5.0
- Wireless Range: 30' Feet (10 Meters)
- Mic Input Type: Dynamic
- Power Amp Type: Stereo Class-D
- Minimum Load Resistance:4 Ohm
- T.H.D.:0.03%(8 Ohm,1KHZ)
- Power Draw:12V 3Amps
- Power:DC 100-240V,50/60Hz(12V DC Adapter)
Independent 4 Channel In Wall Bluetooth Amplifier:
INPUT SELECTION: Audio Input between AUX/B T/MIC
USB PORT: USB Card Reader&USB Charge(5V 1A)
DC 12V IN: 12V DC Power Supply
5.0 BT: Signal LED; BT Wireless Music function allows you connect & Stream
VOL UME/ON/OFF: Master Volume Control with Power ON/OFF
MIC IN: 1/4 Microphone Input Connector Jack
AUX IN: (3.5mm)Audio Input Jack can Connect&Instantly Stream Audio From your Favorite Devices.
6.5" Bluetooth Ceiling Speakers Set
|
6.5" Bluetooth Ceiling Speakers Set
|
5.25" Bluetooth Ceiling Speakers Set
|
Bluetooth Ceiling Speakers Set
|
Bluetooth Ceiling Speakers Set
|
|
|---|---|---|---|---|---|
|
|
|
||||
| Customer Reviews |
228
|
73
|
108
|
148
|
310
|
| Ceiling Speakers size | 6.5 Inches | 6.5 Inches | 5.25 Inches | 6.5 Inches | 5.25 Inches |
| Sold as Pair | 2 PAIRS | 2 PAIRS | 2 PAIRS | 1 PAIR | 1 PAIR |
| Max Power Output | 600W | 640W | 600W | 320W | 300W |
| Sensitivity | 89dB | 89dB | 89dB | 89dB | 89dB |
| Impedance | 8 Ohms | 8 Ohms | 8 Ohms | 8 Ohms | 8 Ohms |
| Frequency Response | 60-20KHZ | 60-20KHZ | 60-20KHZ | 60-20KHZ | 60-20KHZ |
| In Wall Amplifier Channels | 4 Channels | 4 Channels | 4 Channels | 2 Channels | 2 Channels |
| Bluetooth | ✓ | ✓ | ✓ | ✓ | ✓ |
