Product Description
Specification
Nominal Voltage: 12V/24V
Rated Charge Current: 20A
Max. PV Input Voltage: 55 VDC
Max. PV Power: 260W (12V) / 520W (24V)
Controller Terminals: 20 - 6 AWG, 2-pin terminals
Operating Temperature: -31°F - 113°F
Enclosure: IP67
Common Ground: Positive
Renogy 20A PWM Waterproof Charge Controller New Edition of Voyager
New Edition of Voyager
The Voyager is an advanced PWM charge controller suitable for 12V and 24V solar system applications. It features an intuitive LCD screen displaying information such as charging current, battery voltage, and error codes to quickly diagnose potential faults. The Voyager is completely waterproof, and provides multiple battery, controller, and PV electronic protections to ensure charging and usage safety.
Efficient, Stable, and Safe Charging
Utilizing smart PWM technology, the Voyager provides 4-stage charging (Bulk, Absorption, Float and Equalization) in order to protect the battery. It also provides multiple battery, controller, and PV electronic protections to ensure charging and usage safety.
Compact and lightweight
The Renogy Voyager PWM Waterproof Controller is compact and lightweight, making it perfect for applications with limited space. With a weight of only 0.55lb, a height of 3.84 inches and a width of 6.08 inches, this controller is ready to be installed in small spaces.
Common Positive Ground
The Voyager PWM Waterproof Controller is a common positive ground charge controller, beneficial in ensuring charging safety.
Temperature Monitor and Compensation
Fitted with a Remote Temperature Sensor Port, the Voyager can measure battery temperature in real-time and use this data for very accurate temperature compensation, assuring stable and constant charging.
Extremely Low Self-Consumption
In a 12V system, the Voyager PWM Waterproof Controller only needs 0.22w/h or 1.92kmh/365days. Therefore, consuming extremely low levels of energy while working to charge your battery.
System Voltage Automatic Identify
The Voyager PWM Waterproof Controller supports both 12V and 24V systems and can automatically identify system voltage once connected to a Gel, AGM, Flooded battery bank.
Notes:
1. For users using PWM controller in their solar system, we highly recommend you to connect the solar panels in parallel since it will maintain the PV output voltage under which the controller will work in high efficiency.
2. Never install the controller in a sealed enclosure with flooded batteries as gas can accumulate and there is a risk of explosion.
3. The solar controller should be installed as near the battery as possible to avoid efficiency loss.
4. Incorrect battery type setting on the controller may damage your battery. The system auto-recognition is only adapted to Gel, AGM, and Flooded batteries so when using the Voyager to charge a lithium battery bank, please manually set the system voltage otherwise the over-discharged lithium battery will not be activated.
5. To maintain best controller performance, it is recommended to avoid any damage or wear wire going into the controller and make sure all terminals are tighten, inspect any loose, broken, or burnt up connections, and occasionally clean the case using a damp cloth.
Voyager 20A PWM
|
Renogy 100W Solar Panel
|
175W Flexible Solar Panel
|
Adventurer 30A PWM
|
Renogy 40A ANL Fuse Set w/Fuse
|
Wanderer 30A PWM
|
|
|---|---|---|---|---|---|---|
|
|
|
|
||||
| Customer Reviews |
169
|
425
|
1,394
|
771
|
451
|
2,064
|
| Rated Battery Input Voltage | 12VDC / 24 VDC (Auto) | - no data | - no data | 12VDC / 24 VDC (Auto) | - no data | 12VDC |
| Maximum Solar Input Power | 260 W (12V);520 W (24V) | - no data | - no data | 400 W (12V);800 W (24V) | - no data | 400 W (12V Battery) |
| Maximum Solar Input Voltage | 25VDC (12V);55V (24V) | - no data | - no data | 50VDC | - no data | 25VDC |
| Dimensions | 6.08x 3.83 x 1.40 inch | - no data | - no data | 6.56x 4.50 x 1.90 inch | - no data | 6.45x 4.31 x 1.76 inch |
| Weight | 0.6 lbs/ 0.3kg | - no data | - no data | 0.6 lbs/ 0.3kg | - no data | 0.7 lbs/ 0.3kg |
