Nobosund & Douk AudioDoukAudio
  • Douk Audio L1 Mini Stereo Line Level Booster Amplifier Audio Preamp with 20dB Gain and Volume Control
  • To view this video, download

Douk Audio L1 Mini Stereo Line Level Booster Amplifier Audio Preamp with 20dB Gain and Volume Control

4.0 out of 5 stars 282 ratings
鶹's Choice highlights highly rated, well-priced products available to ship immediately.
鶹's Choice
To see product details, add this item to your cart. You can always remove it later.
Save 10% at checkout qualifying items | Terms
on any 2 qualifying items | Terms
on any 3 qualifying items | Terms

Purchase options and add-ons

About this item

  • Mutiple input/output interfaces: with 3.5mm AUX/stereo RCA/5-DIN inputs and stereo RCA/5-DIN outputs, can be compatible with most low-volume audio sources such as ipod, ipad, phone, TV, MP3 player, potable CD player, computer, video game etc., and boost their output to the level needed to drive amplifier or speakers.
  • With built-in amplification and voltage boost circuit: adjustable gain to match better with different audio sources, support DC 5-24V wide input voltage that can share the power supply of amplifiers, while L1 can always work at a high voltage of 26V to provide ±12.5 high output amplitude and max 20dB high gain.
  • Unique design and HiFi clear sound: double-side PCB design, NE5532P op amp with pluggable socket design, convenient to change other op amps to enjoy different sound and bring much DIY fun for audiophiles. High-qaulity sealed potentiometer, with wide frequency bandwidth and excellent dynamic response, the sound is smooth and natural, warm and delicate with ultra-low distortion.
  • Mini size with exquisite appearance, compact and all-metal design for durability and shielding the electronics from electromagnetic interference with noise rejection. Perfect design in size and function, suitable for many scenarios to increase the output level, such as home stereo system, mixer or speaker setup, karaoke, audio recording, party, live stage event etc.
› See more product details

Product details

  • Parcel Dimensions ‏ : ‎ 13 x 9.6 x 8.41 cm; 340 g
  • Date First Available ‏ : ‎ Nov. 3 2020
  • Manufacturer ‏ : ‎ Douk Audio
  • Place of Business ‏ : ‎ ShenZhen, GuangDong 518110,CN
  • ASIN ‏ : ‎ B08L4WYSZ4
  • Item model number ‏ : ‎ XZ-L1
  • 鶹 Rank: #33,234 in Electronics (See Top 100 in Electronics)
  • Customer Reviews:
    4.0 out of 5 stars 282 ratings

Frequently bought together

This item: Douk Audio L1 Mini Stereo Line Level Booster Amplifier Audio Preamp with 20dB Gain and Volume Control
$55.99
Get it by Wednesday, Nov 19
In Stock
Sold by Douk Audio Direct and ships from 鶹 Fulfillment.
+
鶹 Basics 2 RCA Audio Cable for Amplifier,Active Speakers or Subwoofer with Gold-Plated Plugs, 1.22 m, Black
$15.30
In Stock
Ships from and sold by 鶹.ca.
Total price:$00
To see our price, add these items to your cart.
Details
Added to Cart
These items are shipped from and sold by different sellers.
Show details Hide details
Choose items to buy together.
Brief content visible, double tap to read full content.
Full content visible, double tap to read brief content.

Videos for similar products

Previous page

  1. Douk Audio L1-MiINI Stereo Line Level Booster Amplifier Audio Preamp 20dB Gain + Volume Control10
    $64.89

  2. Fosi Audio V1.0G 2 Channel Class D Mini Stereo Amplifier for Home Speakers TPA3116 50W x 2 with Power Supply1,326
    $69.99

  3. ​Nobsound Mini Bluetooth 5.0 Amplifier: 100W HiFi Stereo Amp w/USB/AUX Input, Wireless Audio Receiver for Home/Office Speakers (Black)​​37
    $47.99

  4. NEOHIPO TP10 Phono Preamp for Turntable,Mini Stereo Audio Hi-Fi Phonograph Preamplifier with RCA Input, RCA/3.5MM Output & Low Noise Operation Powered by DC 12V/1A Power Supply18
    $49.99

  5. NEOHIPO BP10 Hi-Fi Stereo Amplifier | 50W×2/100W Mono|Dual Mode (100WX2)| 20Hz-20kHz Response | High SNR ≥100dB | Low Distortion Sound | for Home Theater, Desktop Audio, Bookshelf Speakers25
    $49.99

  6. AIYIMA A07 MAX 2 Channel Amplifier Home Audio 300W*2 TPA3255 Class D Power Amp Bridgeable Mono Stereo Amplifier with 3.5mm Line Output for Passive Bookshelf Desktop Speakers+DC 36V Power Adapter539
    $129.99

  7. AIYIMA A07 Premium TPA3255 Power Amplifier 300Wx2 HiFi Class D Audio Amp Mini 2 Channel Stereo Amplifier for Passive Speaker Desktop Bookshelf Home Theater System with DC 32V Power Adapter1,451
    $113.99

  8. Fosi Audio Box X2 Phono Preamp for Turntable Preamplifier MM Phonograph Preamplifier with Gain Gear Mini Stereo Audio Hi-Fi Pre-Amplifier for Record Player with DC 12V Power Supply2,974
    $89.99

  9. USB Gaming DAC Amp for PC, Headphone Amplifier for Desktop, Mini Amp, Headphone Amp, Digital-to-Analog, w/USB/Mic/AUX Inputs, 3.5MM/6.35MM/COA/Opt/RCA Outputs, Bass & Treble EQ Control, for PS5/PC111
    $49.99
Next page

Product Description

Douk Audio L1
Douk Audio U3
Nobsound NS-08E
Nobsound NS-10P
Douk Audio P1
Douk Audio X1
Buying Options
Customer Reviews
4.0 out of 5 stars 282
4.4 out of 5 stars 743
4.0 out of 5 stars 686
4.0 out of 5 stars 359
4.2 out of 5 stars 977
4.2 out of 5 stars 445
Features Line Level Booster Mini Class A Headphone Amplifier Vacuum Tube Headphone Amplifier Vacuum Tube Preamplifier Bluetooth Vacuum Tube Preamp & Headphone Amplifier & USB DAC Bluetooth Vacuum Tube MM Phono Amplifier & Active SUB Output
Douk Audio T3 PRO
Nobsound NS-01G PRO
Douk Audio M1 PRO
Douk Audio M4
Nobsound G2
Douk Audio VU3
Buying Options
Buying Options
Buying Options
Buying Options
Customer Reviews
4.0 out of 5 stars 156
—
4.4 out of 5 stars 625
4.2 out of 5 stars 324
4.5 out of 5 stars 681
4.3 out of 5 stars 373
Features Vacuum Tube MM Phono Preamplifier 100W Bluetooth Amplifier & USB Sound Card 320W Bluetooth Amplifier & U-Disk Input & Active SUB Output 50Wx4 2-CH/4-CH Bluetooth Amplifier 100W PBTL Subwoofer Amplifier 2-Way Amplifier/Speaker Audio Switch & VU Meter
Douk Audio L1
L1

Douk Audio L1

Introduction

Douk Audio L1 is a stereo amplifier with built-in voltage boost and amplification circuits, designed to boost the output of virtually any line level audio source (such as TV, video games, MP3 players, ipod, phone, tablet etc.) to max 20dB. L1 features its wide gain range, wide frequency response, excellent S/R and HiFi sound, to bump the output level of the audio devices which are with an inherently low level output so as to match other sources, or to allow the use of a longer cable run than normal between components.

Warm Tips

  1. 3.5mm AUX input with priority, please make sure AUX cable has been disconnected if you want 5-DIN or stereo RCA input.
  2. 5-DIN and stereo RCA output can work at the same time.
  3. Equipped with USB to DC cable, NOT include power adapter, can use phone charger/power bank/computer to power it.

Packing List

  • 1*L1 Stereo Line Level Booster
  • 1*USB to DC Cable
  • 1*3.5mm to RCA Cable
  • 1*2:2 RCA Cable
2
1

Parameters

Audio input 3.5mm AUX / Stereo RCA / 5-DIN
Audio output Stereo RCA / 5-DIN
Gain 20dB (Adjustable)
Frequency response 20Hz-20KHz ( ± 0.5dB)
THD 0.06% Max
S/N ratio >80dB
Input sensitivity 150mW/50KHz at 1KHz
Max output amplitude ±12.5
Input voltage DC 5-24V
Working voltage DC 26V
Dimensions(W*D*H) 87*63*48mm / 3.43*2.48*1.89in
Package dimensions(W*D*H) 150*90*110mm / 5.91*3.54*4.33in
Net weight 155g / 0.34lb
Package weight 400g / 0.88lb

Brands in this category on 鶹

Sponsored

Product Summary: Douk Audio L1 Mini Stereo Line Level Booster Amplifier Audio Preamp with 20dB Gain and Volume Control

From Douk Audio

4.0 out of 5 stars, 282 ratings

Customer reviews

50+ viewed in past month

Price

No featured offers available

Other sellers

Other sellers

About this Item

  • Mutiple input/output interfaces: with 3.5mm AUX/stereo RCA/5-DIN inputs and stereo RCA/5-DIN outputs, can be compatible with most low-volume audio sources such as ipod, ipad, phone, TV, MP3 player, potable CD player, computer, video game etc., and boost their output to the level needed to drive amplifier or speakers.
  • With built-in amplification and voltage boost circuit: adjustable gain to match better with different audio sources, support DC 5-24V wide input voltage that can share the power supply of amplifiers, while L1 can always work at a high voltage of 26V to provide ±12.5 high output amplitude and max 20dB high gain.
  • Unique design and HiFi clear sound: double-side PCB design, NE5532P op amp with pluggable socket design, convenient to change other op amps to enjoy different sound and bring much DIY fun for audiophiles. High-qaulity sealed potentiometer, with wide frequency bandwidth and excellent dynamic response, the sound is smooth and natural, warm and delicate with ultra-low distortion.
  • Mini size with exquisite appearance, compact and all-metal design for durability and shielding the electronics from electromagnetic interference with noise rejection. Perfect design in size and function, suitable for many scenarios to increase the output level, such as home stereo system, mixer or speaker setup, karaoke, audio recording, party, live stage event etc.

Product description

How to use: 1. Please prepare a power adapter and connect power source and L1 via power cable, you can use DC 5-24V power supply, also can use phone charger/power bank/computer as power source to connect L1 via USB to DC cable. 2. Connect your audio source such as phone, ipod, MP3, ipad, TV or other audio device with low level output to L1 via RCA/3.5mm AUX/5-PIN DIN input interface. 3. Connect backend audio device such as preamp, amplifier, active speaker etc. to L1 via RCA/5-PIN DIN output interface. 4. Rotate the power/volume knob on the top panel to turn L1 on, play music on your audio source and turn on the backend audio device in order, then continue to rotate the volume knob to adjust the gain until you feel perfect. Introduction Douk Audio L1 is a stereo amplifier with built-in voltage boost and amplification circuits, designed to boost the output of virtually any line level audio source (such as TV, video games, MP3 players, ipod, phone, tablet etc.) to max 20dB. L1 features its wide gain range, wide frequency response, excellent S/R and HiFi sound, to bump the output level of the audio devices which are with an inherently low level output so as to match other sources, or to allow the use of a longer cable run than normal between components. Warm Tips 1. 3.5mm AUX input with priority, please make sure AUX cable has been disconnected if you want 5-DIN or stereo RCA input. 2. 5-DIN and stereo RCA output can work at the same time. 3. Equipped with USB to DC cable, NOT include power adapter, can use phone charger/power bank/computer to power it. Parameters Audio input: 3.5mm AUX / Stereo RCA / 5-DIN Audio output: Stereo RCA / 5-DIN Gain: 20dB (Adjustable) Frequency response: 20Hz-20KHz ( ± 0.5dB) THD: 0.06% Max S/N ratio: >80dB Input sensitivity: 150mW/50KHz at 1KHz Max output amplitude: ±12.5 Input voltage: DC 5-24V Working voltage of amplification part: DC 26V Dimensions(W*D*H): 87*63*48mm / 3.43*2.48*1.89in Package dimensions(W*D*H): 150*90*110mm / 5.91*3.54*4.33in Net weight: 155g / 0.34lb Package weight: 400g / 0.88lb Packing List 1*L1 Stereo Line Level Booster 1*USB to DC Cable 1*3.5mm to RCA Cable 1*2:2 RCA Cable
