| Educational objective(s) | Electronics Learning Programming and Robotics |
|---|---|
| Model Number | PIXHAWK 2.4.8 |
| Assembly Required | No |
| Batteries Required? | No |
| Batteries Included? | No |
| tech_spec_battery_description_toys | Lithium-Ion Polymer |
| Material type(s) | Plastic |
| Colour | Black |
| Manufacturer recommended age | 14 years and up |
| Item model number | PIXHAWK 2.4.8 |
| Product Dimensions | 17.02 x 10.67 x 5.08 cm; 36.29 g |
| ASIN | B0BY1797VF |
Product information
Additional Information
| Customer Reviews |
4.2 out of 5 stars |
|---|---|
| 鶹 Rank |
|
| Date First Available | June 7 2023 |
Feedback
Frequently bought together
This item: Radiolink PIXHAWK 2.4.8 Flight Controller, Support OSD and Date telemetry, Automation Software Tested FC with 2S-12S Power Module, FC for Rotary/2-8 Copter/Fixed Wing/VTOL/Car/Boat/Robot/Mower
$219.99
Get it by Monday, Jan 12
Only 5 left in stock.
+
$49.99
Get it by Monday, Jan 12
Only 10 left in stock.
Total price:$00
To see our price, add these items to your cart.
Choose items to buy together.
Videos for similar products
Brand in this category on 鶹
Sponsored
From the brand
-
Radiolink Electronic Co., Ltd. was established in 2003. We are specialized in researching, developing, and producing RC transmitters, flight controllers, receivers, GPS, drones, ESC, airplanes, and balance chargers.
We have professional research and develop team, applied automatic producing & testing instruments to provide high-quality, diversified products to our users, and also include friendly after-sales service.
-
RC Transmitter and Receiver
-
Airplane/Flight Controller
-
Surface Controller & Receiver
-
Radiolink Flight Contollers
-
Balance Charger&Batteries&GPS
-
-
-
-
-
-
-
-
-
-
Product Description
Complete automatic, anti-static form SMT to weldingachieved less interference of inner components.Full mechanical, anti-static fully automated welding from patch to backhand welding, to achieve reducinginterference of geomagnetic sensors, which greatly improves the efficiency of production inspection. All the chips such as processor sensors and others are imported with whole package by primary agency. Dust-free workshop ensures itsdurability. The Automation software Testing System developed by Radiolink ensures the quaity of every function of every PIXHAWK. As the only PlX manufacturer that realizes test automation from the sensor to the interface, testing eficiency of Radiolink is far more than traditional manual testing.
Pix Features
A Good Choice for DIY Drone
Complete installation tutorial, easy to set up, eliminating the cumbersome and complicated installation and calibration process, making your DIY racing drone easier.
Support Model
Radiolink PIXHAWK usually used with Long-wheelbase Quadcopter or 6-8 Axis Multirotor. Supporting Althold, Stabilize, Loiter, Poshold, Return and other flight modes.
Package Included
- PIXHAWK x 1
- Power Module x 1
- Safety Switch x 1
- Three-wire Servo Cable x 1
- Connection Cable x 2
- Micro-SD Card(4G) x 1
- Buzzer x 1
- Mounting Foam x 2
Troubleshooting
Q1：Why the FC fail to be armed?
A1: There may be 4 reasons.
1. Didn't calibrate accelerometer, compass, radio, or ESC. Please calibrate them; 2. Wrong channel phases. Take Radiolink AT9S as an example. The throttle is reverse and the rudder is normal; 3. Disarm in Position Hold Mode or Loiter Mode that needs GPS functions properly. Please set flight mode as Altitude Mode or Manual Mode to disarm PIXHAWK; 4. Geomagnetism may change. Please calibrate the compass again.
Q2：Motors don't spin.
A2：There may be 3 reasons.
1. Didn't calibrate ESC. Please calibrate ESC; 2. The receiver signal is not compatible with PIXHAWK. The RCIN port supports SBUS/PPM. The SPKT/DSM supports spectrum receivers. Please make sure your receiver is connected to the right port and the signal is compatible with PIXHAWK; 3. Servo travel is not suitable for ESC. Please adjust servo travel until the motors spin.
Radiolink PIX Flight Controller
|
Radiolink Mini Pix Flight Controller
|
Radiolink M8N GPS SE100
|
Radiolink M8N GPS TS100
|
|
|---|---|---|---|---|
|
|
||||
| Customer Reviews |
11
|
9
|
66
|
29
|
| Size | 3.22''*2.04''*0.65'' | 1.53''*1.53''*0.47 | 1.89''*1.65''*0.59'' | 1.18''*1.26''*0.47'' |
| Weight | 1.34oz | 0.53oz | 1.23oz | 0.70oz |
| Connectors | PH 1.25 | GH 1.25 | GH 1.25 or PH 1.25 | PH 1.25 |
| Mission Planner and Firmware | Ardupilot Mission Planner/firmware | Radiolink or Ardupilot Mission Planner/firmware | / | / |
| PWM Output Channels | 8 | 6 | / | / |
| Position Accuracy | / | / | Up to 50 cm with Dual Modes, 250 cm with Single Mode | Up to 50 cm with Dual Modes, 250 cm with Single Mode |
| Number of Satellites | / | / | Positioning 20 Satellites in 6 Secondsat open ground | Positioning 20 Satellites in 6 Secondsat open ground |
| Compatible with | Rotary/3-8 copter/Airplane/VTOLCar/Boat/Robot/Mower | Airplane/3-6 Copters/Helicopter/VTOL/Car/Boat | PIXHAWK | Radiolink Mini Pix |
