| Brand | PALPEAL |
|---|---|
| Manufacturer | PALPEAL |
| Place of Business | Huizhou Shanxing E-commerce Co.Guang Dong,China |
| Mounting Hardware | Antenna Splitter, Antenna paddle |
| Batteries Required | No |
| Manufacturer | PALPEAL |
| Parcel Dimensions | 55.88 x 40.64 x 15.24 cm; 6.8 kg |
| ASIN | B0F3NDQ2MW |
Product information
Additional Information
| Date First Available | April 4 2025 |
|---|---|
| Customer Reviews |
4.6 out of 5 stars |
| 鶹 Rank |
|
Feedback
Videos for similar products
Product Description
PALPEAL AMP668 10 Channel Antenna Distribution System for UHF Wireless Microphone System
Product Features :
PALPEAL AMP668 Antenna Distribution System can expand the signals of the wireless microphone system by splitting one pair of the antennas to wireless receiver.and enable wireless microphone signals up to 2,200 feet,It also amplifies RF signals to compensate for insertion loss that results from splitting signal power to multiple outputs.And can supply the power port to the UHF wireless system.
1. It covers UHF 400-970MHz frequency band
2. Compatible with Shure Sennheiser AKG ... Brand UHF wireless microphone
3. It supports 5 units 2-antenna wireless microphone receiver or 2 units 4-antenna wireless microphone receiver and 1 units 2-antenna microphone
receiver.
4. Use the cascade method to cascade up to 8 antenna splitters for More wireless microphone systems
Technical parameters:
ACTIVE DIRECTIONAL ANTENNA:
Antenna type: log periodic dipole oscillator array
RF frequency range: 400-970MHz
Power supply: 9-15V,150mA
Connecting terminal: BNC Port Coaxial Cable
Impedance: 50 Ω
Head type: BNC
Antenna gain: 7.5dBi
ANTENNA DISTRIBUTION SYSTEM:
Carrier frequency range: 400-970MHz
Type of input/output antenna connector: BNC
Impedance: 50 Ω
Channel：10 channels output
Output external power supply: DC 12V 800mA
Input power: AC100-260V
Antenna Paddle Gain Adjustment:
1.Gain switch
Adjust the four-position gain switch to compensate for the calculated cableloss,based on the length and type of cable.
2.Gain mode LED
Indicates the current gain switch setting.
3.RF Overload LED
Indicates a strong RF signal that is overloading the antenna amplifier,which results in distortion or poor performance.Increase the distance between the antenna and transmitter,or lower the antenna gain setting.
4.BNC connector
Connect to a receiver or antenna combiner with RF inputs that supply 8-15V DC bias
Antenna paddle correct placement：
1.The signal transmission of this equipment has directivity，In the direction of the range to obtain a better transmission effect.
2.Mount antennas at least 1.5 meters apart,and placement the height more than 1.8meters.
3.Position antennas so there is nothing obstructing a line of sight to the transmitter (including the audience)
4.Keep antenna away from large metal objects.
5.The antennas will be affected by the weather and environment,the moist-ure and rain will affect the efficiency and safety of the BNC connector andcable ,
when used outside,please put the antenna in the dry place
Products Include:
Antenna paddle * 2
Antenna splitter * 1
Power Adapter * 1
Power Output Cable * 4
BNC Connection Cable * 10
10 FT Antenna Cable (Coaxial Cable) * 2
Metal CASE * 1
PALPEAL AMP668 Antenna Distribution System Connection Method:
PALPEAL AMP668 Antenna Distribution System (8 output port + 2 cascade port)
1. Support 10 units 1-antenna wireless microphone receiver.
2. Support 5 units 2-antenna wireless microphone receiver.
3. Support 2 units 4-antenna wireless microphone receiver and 1 units 2-antenna wireless microphone receiver
Multi Antenna Distribution System Connect Method:
Use the cascade method to cascade up to 8 antenna splitters for More wireless microphone systems
If you want to add antenna splitter，You can buy extra in this store
