Product Description
True to the spirit of Noctua’s redux line, the NH-U12S redux is a streamlined, accessibly priced version of the iconic NH-U12S that has established itself as a benchmark for slim, highly compatible 120mm CPU coolers. The redux version uses the same proven heatsink layout that ensures 100% compatibility with tall RAM modules as well as excellent case and PCIe compatibility. Thanks to the popular NF-P12 redux-1700 PWM fan with automatic speed control, it provides high performance under load and runs whisper-quiet at idle. At the same time, Noctua’s renowned, professional SecuFirm2 mounting system and the pre-applied NT-H1 thermal compound make installation child’s play. Backed up with Noctua’s trusted quality, the NH-U12S redux is a smart, affordable choice for a quiet, high-quality 120mm cooler.
Classic 120mm tower size for excellent case and PCIe compatibility
Standing 158mm tall, the NH-U12S redux is short enough to fit most modern mid- or high-end tower cases. Measuring 125mm wide (including fan and fan clips), the cooler stays clear of the top PCIe slot on most standard ATX or Micro-ATX motherboards, ensuring optimum compatibility with multi-GPU setups.
100% RAM compatibility
Thanks to its slim design with only 45mm fin depth, the NH-U12S redux will not overhang the RAM slots on any current platform. This gives the user full access to the memory modules and ensures 100% compatibility with modules that feature tall heat-spreaders or RGB lighting.
Proven NF-P12 fan with PWM
Specifically designed for pressure-demanding applications such as on heatsinks, the classic NF-P12 is a long-standing favourite among quiet cooling enthusiasts. The higher-speed 1700rpm redux line version supports PWM for automatic speed control, which allows it to run near silent most of the time and provide massive performance when necessary.
Optional dual-fan kit
The optional NA-FK1 fan kit makes it possible to upgrade the NH-U12S redux with a second fan in order to achieve even better performance. Containing a second NF-P12 redux-1700 PWM fan, fan clips, anti-vibration pads, a y-cable and Low-Noise Adaptors, it gives plenty of options to fine-tune the cooler for further improved efficiency or quietness of operation.
Measurements
- Height (without fan): 158 mm
- Width (without fan): 125 mm
- Depth (without fan): 45 mm
- Height (with fan): 158 mm
- Width (with fan): 125 mm
- Depth (with fan): 71 mm
- Weight (without fan): 550 g
- Weight (with fan): 710 g
Material
Nickel plated Copper (base and heat-pipes), aluminium (cooling fins)
Cooler Specifications
Scope of Delivery
- NH-U12S redux heatsink
- NF-P12 redux-1700 PWM fan
- 4x NA-AVP1 grey anti-vibration pads
- Fan mounting clips (one pair)
- NT-H1 high-grade thermal compound (pre-applied)
- SecuFirm2 mounting kit
Fan compatibility
120x120x25 mm
Streamlined redux edition
Following the idea of Noctua’s redux line, the NH-U12S redux takes the proven concept of the original NH-U12S and reduces it to its essential core: a quiet, quality-made 120mm cooler with streamlined accessories that is highly compatible and easy to install.
NH-U12S
|
NH-U12S TR4-SP3
|
NH-U12S DX-4677
|
NH-U12S redux
|
NH-U12S chromax.black
|
NH-U12A
|
|
|---|---|---|---|---|---|---|
|
|
|
|||||
| Customer Reviews |
5,168
|
231
|
11
|
4,098
|
— |
3,475
|
| LGA1851, LGA1700 | ✓ | X | X | ✓ | ✓ | ✓ |
| LGA1200, LGA115x (LGA1150, LGA1151, LGA1155, LGA1156) | ✓ | X | X | ✓ | ✓ | ✓ |
| LGA20xx Square ILM | with NM-i20xx | X | X | with NM-i20xx | with NM-i20xx | with NM-i20xx |
| LGA20xx Narrow ILM | X | X | X | X | X | X |
| LGA4189 | X | with NM-i4189 | with NM-i4189 | X | X | X |
| LGA4677 | X | with NM-i4677 | ✓ | X | X | X |
| AM5 | ✓ | X | X | ✓ | ✓ | ✓ |
| AM4 | ✓ | X | X | ✓ | ✓ | ✓ |
| TR4, SP3, sTRX4, sWRX8 | X | ✓ | X | X | X | X |
| sTR5, SP6 | X | with NM-TR5-SP6 | with NM-TR5-SP6 | X | X | X |
