  • Cable Matters Internal Mini SAS to SATA Cable 3.3 Feet (SFF-8087 to SATA Forward Breakout)
  • To view this video, download

Cable Matters Internal Mini SAS to SATA Cable 3.3 Feet (SFF-8087 to SATA Forward Breakout)

4.6 out of 5 stars 788 ratings
To see product details, add this item to your cart. You can always remove it later.

Purchase options and add-ons

About this item

  • Internal Mini SAS data cable connects a RAID or PCIe controller with an SFF-8087 port to 4 discrete SATA drives; Mini SAS to SATA adapter provides reliable internal connectivity between a Serial attached SCSI controller card in a computer system and direct attached storage devices with a SATA connector
  • Leverage hardware raid performance with this SATA multi-lane cable; Two cables can connect up to 8 SATA drives to span RAID controller arrays and share performance across two PCIe 2.0 x8 lanes with compatible host bus adapters; Supports up to 6Gbs data transfer rate per drive
  • DIY or pro installers both appreciate the convenience of a forward fan-out cable with an internal mSAS connector when expanding storage needs; 3 foot cable harness of SAS to SATA cable provides sufficient length for internal cable management; Slim ribbon cables minimize airflow impact in a computer case
  • Flexible design of SAS breakout cable includes acetate cloth tape over slim ribbon cables for strain relief to protect cables without rigidity; Woven mesh sheath covers half of the cable for easy routing; P1 to P4 markers provide easy ID after installation; Low profile SATA connectors have easy-grip treads with stainless steel latches to prevent accidental disconnection and reduce vibration disconnection
  • SFF-8087 compatible with popular RAID cards such as 3Ware 9650SE-8LPML RAID, Adaptec ASR-5805/512MB SAS RAID / 2258200-R 5405 RAID / 2258500-R 51645 RAID, Dell PERC H700 Raid / PERC H200, Dell PowerEdge 8-port SAS SATA Controller / PERC H310, HighPoint RocketRAID 2720 / RocketRAID 620 / RocketRAID 4520 / RocketRAID 4522, LSI Logic SAS9211-8I HBA Card, StarTech.com PCI Express RAID, Syba 4-Port RAID HyperDuo / PCI Express SATA II 4 x Ports RAID, Supermicro AOC-SAS2LP-MV8 8-Channel SAS/SATA
› See more product details

Product details

  • Is discontinued by manufacturer ‏ : ‎ No
  • Product Dimensions ‏ : ‎ 20.32 x 15.75 x 0.76 cm; 50 g
  • Date First Available ‏ : ‎ Sept. 21 2015
  • Manufacturer ‏ : ‎ Cable Matters
  • Place of Business ‏ : ‎ Southborough, MA 1772, US
  • ASIN ‏ : ‎ B012BPLYJC
  • Item model number ‏ : ‎ 104016
  • 鶹 Rank: #68 in SATA Cables
  • Customer Reviews:
    4.6 out of 5 stars 788 ratings

Frequently bought together

This item: Cable Matters Internal Mini SAS to SATA Cable 3.3 Feet (SFF-8087 to SATA Forward Breakout)
$19.99
Get it by Monday, Nov 17
In Stock
Sold by Cable Matters Canada and ships from 鶹 Fulfillment.
+
10Gtek Internal PCI Express SAS/SATA HBA RAID Controller Card, LSI SAS2008 Chip, 8-Port 6Gb/s, Same as LSI 9211-8I
$118.99
Get it by Monday, Nov 17
In Stock
Sold by 10Gtek and ships from 鶹 Fulfillment.
+
Cable Matters 2-Pack 15 Pin SATA to 4 SATA Power Splitter Cable - 18 Inches
$16.99($8.50/count)
Get it by Friday, Nov 21
In Stock
Sold by Cable Matters Canada and ships from 鶹 Fulfillment.
Total price:$00
To see our price, add these items to your cart.
Details
Added to Cart
These items are shipped from and sold by different sellers.
Show details Hide details
Choose items to buy together.
Brief content visible, double tap to read full content.
Full content visible, double tap to read brief content.

Videos for similar products

Previous page

  1. StarTech.com 1m Internal Mini SAS to SATA Cable - SFF-8643 to 4X SATA (SAS43SAT1M)55
    $30.71

  2. YIWENTEC Mini SAS 36P SFF-8087 to 4 SATA Target Hard Disk Connector Data Cable 0.5m648
    $11.69

  3. OIKWAN Mini SAS to 4 SATA Cable, 36 Pin SFF 8087 Host/Controller to 7 Pin SATA Target/Backplane, Compatible with PERC H310, RAID Controller 3Feet(2 Pack)172
    $29.99

  4. Internal Mini SAS to Mini SAS Cable, SFF8087 36 Pin to SFF8087 36Pin Data Cable Male Cord for Server, Raid Controller, SAS/SATA HBA, Data Storage System-1.6FT102
    $16.99

  5. YIWENTEC Internal HD Mini SAS SFF-8643 Host to 4 SATA Target Hard Drive Cable (8643 SATA 1M)237
    $17.09

  6. OIKWAN Internal Mini SAS to SATA Cable, SFF-8643 to SATA Forward Breakout Compatible with Raid Controller Hard Drive (3.3ft)213
    $17.99

  7. LSI SAS 9300 16I HBA Card, 12Gbps SATA SAS Port HBA Host Bus Adapter Card for for Linux for VMware for Freebsd14
    $71.42

  8. CableDeconn SFF-8643 Internal Mini SAS HD to (4) 29pin SFF-8482 connectors with SAS 15pin Power Port 12GB/S Cable (1M) (H0204)228
    $22.99

  9. StarTech.com 15.7 in (400 mm) SATA Power Splitter Adapter Cable - M/F - 4x Serial ATA Power Cable Splitter (PYO4SATA)6,704
    $11.57

  10. StarTech.com 15.7 in (400 mm) SATA Power Splitter Adapter Cable - M/F - 4x Serial ATA Power Cable Splitter (PYO4SATA)6,704
    $11.57
Next page

From the brand

Previous page

  2. Cable Matters, with headquarters in Southborough, Massachusetts, offers a complete line of cables, adapters, docking stations, and networking products for the home, office, and data center. Cable Matters offers first-class, quality, and affordable products backed by an exceptional customer experience.

  3. 102025
    300029
    202013
    160001

    The Versatile Connectivity

    Visit the store

  4. 400001
    400013
    402030
    400002

    The Reliable Connectivity

    Visit the store

  5. Brand Story_2
  6. Brand Story_3
Next page

Product Description

1

DIY or PRO Computer Essential

The Cable Matters Mini-SAS to 4 SATA Forward Breakout Cable is an essential component of a hardware RAID configuration. This multi-lane forward cable coverts Mini-SAS connectors on RAID controllers (that are often shipped without cables) to 4 SATA drives. The combination of a slim ribbon cable design in a woven mesh sheath with locking connector latches provides a professional installation that minimizes the impact on airflow in a computer case.

Storage Expansion

Maximize the capacity of your RAID configuration with this robust but flexible cable that is built to withstand 24/7 use.

Important Notes

- Pair with a 4 port SATA to power splitter cable to provide power to the drives

- Data transfer speed is determined by the capabilities of your SAS controller and SATA drives

Cable Specifications

- Host/Controller Connection: 1 x 36 pin Mini-SAS SFF-8087 - male with latch

- SATA Drive Connections: 4 x 7 pin SATA receptacle - female with latch

- Length: 1m

- Wire - 30 AWG Style 207044 flat ribbon cable

- Compatible with 2.5", 3.5" SATA I, II, III hard drives

SATA 3.0 Cable
4 Pin to SATA
SATA to SATA
SATA to 2x SATA
SATA to 4x SATA
Mini SAS to SATA Breakout
Buying Options
Customer Reviews
4.7 out of 5 stars 2,644
4.6 out of 5 stars 2,173
—
4.7 out of 5 stars 818
4.6 out of 5 stars 972
4.6 out of 5 stars 788
Count 3-Pack 3-Pack 3-Pack 3-Pack 2-Pack 1-Pack
Model Number 104007 104009 104011 104012 104015 104016

Brands in this category on 鶹

Sponsored

Product Summary: Cable Matters Internal Mini SAS to SATA Cable 3.3 Feet (SFF-8087 to SATA Forward Breakout)

From Cable Matters

4.6 out of 5 stars, 788 ratings

Customer reviews

50+ viewed in past month

Price

No featured offers available

Other sellers

Other sellers

About this Item

  • Internal Mini SAS data cable connects a RAID or PCIe controller with an SFF-8087 port to 4 discrete SATA drives; Mini SAS to SATA adapter provides reliable internal connectivity between a Serial attached SCSI controller card in a computer system and direct attached storage devices with a SATA connector
  • Leverage hardware raid performance with this SATA multi-lane cable; Two cables can connect up to 8 SATA drives to span RAID controller arrays and share performance across two PCIe 2.0 x8 lanes with compatible host bus adapters; Supports up to 6Gbs data transfer rate per drive
  • DIY or pro installers both appreciate the convenience of a forward fan-out cable with an internal mSAS connector when expanding storage needs; 3 foot cable harness of SAS to SATA cable provides sufficient length for internal cable management; Slim ribbon cables minimize airflow impact in a computer case
  • Flexible design of SAS breakout cable includes acetate cloth tape over slim ribbon cables for strain relief to protect cables without rigidity; Woven mesh sheath covers half of the cable for easy routing; P1 to P4 markers provide easy ID after installation; Low profile SATA connectors have easy-grip treads with stainless steel latches to prevent accidental disconnection and reduce vibration disconnection
  • SFF-8087 compatible with popular RAID cards such as 3Ware 9650SE-8LPML RAID, Adaptec ASR-5805/512MB SAS RAID / 2258200-R 5405 RAID / 2258500-R 51645 RAID, Dell PERC H700 Raid / PERC H200, Dell PowerEdge 8-port SAS SATA Controller / PERC H310, HighPoint RocketRAID 2720 / RocketRAID 620 / RocketRAID 4520 / RocketRAID 4522, LSI Logic SAS9211-8I HBA Card, StarTech.com PCI Express RAID, Syba 4-Port RAID HyperDuo / PCI Express SATA II 4 x Ports RAID, Supermicro AOC-SAS2LP-MV8 8-Channel SAS/SATA

Product description

Connect More with Cable Matters SATA Cabling Products DIY or PRO Computer Essential The Cable Matters Mini-SAS to 4 SATA Forward Breakout Cable is an essential component of a hardware RAID configuration. This multi-lane forward cable coverts Mini-SAS connectors on RAID controllers (that are often shipped without cables) to 4 SATA drives. The combination of a slim ribbon cable design in a woven mesh sheath with locking connector latches provides a professional installation that minimizes the impact on airflow in a computer case. Storage Expansion with a Lifetime Warranty Maximize the capacity of your RAID configuration with this robust but flexible cable that is built to withstand 24/7 use. A lifetime warranty is included with this Mini-SAS to SATA cable for peace of mind when purchasing. Important Notes - Pair with a 4 port SATA to power splitter cable to provide power to the drives - Data transfer speed is determined by the capabilities of your SAS controller and SATA drives Cable Specifications - Host/Controller Connection: 1 x 36 pin Mini-SAS SFF-8087 – male with latch - SATA Drive Connections: 4 x 7 pin SATA receptacle – female with latch - Length: 3.3 Feet - Wire – 30 AWG Style 207044 flat ribbon cable - Compatible with 2.5", 3.5" SATA I, II, III hard drives - RoHS compliant Warranty Limited Lifetime Warranty and Lifetime Product Support
