True Universal Backup Camera——Compatible with 95% of Monitors on the Market with RCA Video Input

• Tenpmas's latest back up camera supports 4 video signal formats, 4pin connector, compatible with 95% of monitors on the market with RCA video input: Dual DIN Stereo Radio Mainframes, OEM Navigations, Android DVD Players, TFT/LCD monitors and more. If you don't know what video format your Android navigation supports, Vtopek P069 rear view camera will be your optimal choice! You can keep holding the button until the screen is displayed.
• Not compatible with dash camera/mirror dash cam because 4pin definition is different!
• Easy to use——One Button Control——The industry's first reverse camera compatible with multiple video output signals, suitable for almost all hosts with RCA inputs on the market.
• Upgraded rv backup camera with 360°rotatable lens,to achieve flexible installation, no need to care about the installation direction. And the rear camera can be adjusted 45° up/down/left and right, so that you can find the best viewing angle and avoid the restricted view, without worrying about the image effect of the parking camera is too high or too low.

Press the button for 3 seconds to switch the corresponding signal mode, 8 video output signals

Using the bottom to switch the different signal inputs, including the mirror and original image of NTSC and PAL, AHD 1080P and 720P.

• NTSC Mirror Image
• NTSC Original Image
• PAL Mirror Image
• PAL Original Image
• AHD 720P 25fps Mirror Image
• AHD 720P 25fps Original Image
• AHD 1080P 25fps Mirror Image
• AHD 1080P 25fps Original Image

NOTE: If connect this car rear view camera to a factory/non-universal radio, please separately order a suited hamess to complete installation, because diferent radio need different harness to work together, you can send the your monitor details and we wil help you find the adapter and how to set it up.

AHD 1080P Good Clearity Image at Day and Night

Our AHD 1080P camera provides more stable video signal transmission, less interference and delay. High definition is better than most reverse cameras in the market.

Guide Line On/Off

In the initial state, the camera does not display parking guide lines. Cut the green wire if necessary. Reconnecting a cut green line will not display the parking guidelines. Besides，this AHD 1080P backup camera's body can be rotated for 360 degrees, you can get a perfect view with all kinds of position installation.

Rear camera not working after installation? ---How to troubleshoot?

1. Does not display the image

• Check whether the line connection is connected in accordance with the instructions, especially the reverse trigger line, part of the car navigation reverse trigger line connected to the plug, to cut and then connected!
• Don't use other wires, different 4pin connecting wires have different definitions, use our full set of wires!

2. The camera system is selected correctly

• The video format of the host should be the same as our camera format, especially AHD 1080P, some monitors do not support this format.
• Some vehicles only support CVBS mode, AHD mode is not compatible, you need to manually switch the corresponding format to work properly.
• If you are not sure about the video format of your in-vehicle display, you can press and hold the button until the screen is displayed normally.

3. No image/blue screen/ripple after installation

• German cars and some models of American cars, due to the voltage interference, the working voltage is extremely unstable leading to the camera not working properly.
• If this is the case, you can tell us, we can send you a rectifier accessories, after installation can work normally.

The above 3 points can effectively troubleshoot the reason why the rear camera is not compatible with your vehicle, if you have any other use problems, please find us through �鶹�� platform.
