Autel TPMS MX-Sensor combines both 315MHz + 433MHz frequencies into one TPMS sensor with the highest industry vehicle coverage. Built to match or exceed OEM sensors in frequency strength and durability, MX-Sensors are 100% ID clone-able with no relearn required and offer latest model vehicle coverage because they quickly update with an Autel wireless programming tool.
Complete TPMS Coverage in One Sensor: dual frequency 315MHz & 433MHz sensor covers 98% vehicle on the road.
Press Release: exclusive press release valve provides the interchangeable rubber & metal valve stems easy removal and replacement by hand without extra tool.
Max Signal Strength: maximum sensor signal strength to program up to 16 sensors wirelessly including sensors already mounted on the wheel.
Quality Same as OE Sensors: Autel MX-Sensor is tested and certified to meet SAE industry standard J1205 / J1206 and free from manufacturing defects for a period of 24 months or 24,000 miles, whichever option comes first.
Lower Weight: 12g Lower MX-Sensor weight is significantly lighter than most sensors, ensuring greater security and stability for durable use.
Battery Reliability: superior sensor battery power provides maximum sensor life (4-6 years), longer than most sensors, ensuring greater replacement value.
Unlike other regular TPMS Sensor with single frequency for specific car model, Autel TPMS MX-Sensor conbines 4 key elements in 1-SKU sensor:
315 & 433MHz, Interchangeable Metal/ Rubber Valve Stems
Press-out and Click-in design makes you complete the TPMS sensor replacement in an easiest way.
98% COVERAGE: 315MHz & 433MHz Dual Frequency in 1 sensor, saving inventory and serving for 98% vehicles on the road, first choice for large tire repair shops and home technicians.
100% Clone-able: if programmed by Autel TPMS programming tools, no relearn is needed.
Autel MX-Sensor is built to match or exceed OEM sensors in frequency strength and durability. AUTEL high-quality MX-Sensor is tested and certified to meet SAE industry standard J1205 / J1206 testing. Autel provides MX-Sensor free from manufacturing defects for a period of 24 months or 24,000 miles, whichever option comes first. Each Autel MX-Sensor has a series number for assuring quality control. The series number is imprinted on the sensor or can be read with Autel TPMS tools. With the series number, Autel can track the sensor quality from our factory manufacturing to ensure only the highest quality parts are installed.
Battery Lifespan: 4-6 Years
Operating Temperature: -40°C to +125°C
Pressure Monitoring Range: 0 to 800 kPa
Pressure Reading Accuracy: ±10 kPa
Working Miles: 24000 Miles
Light Weighted: 11g
The exclusive Autel MX-Sensor is patented with press-release valve design, allowing rubber and metal sensor valves to freely interchange by hand, without requiring a tool for sensor head fitting.
1. Loosening the tire: Remove the valve cap and core and deflate the tire. Use the bead loosener to unseat the tire bead.
2. Dismounting the tire: Clamp the tire onto the tire changer, and adjust the valve at 1 o'clock relative to the tire separation head. Insert the tire tool and lift the tire bead onto the mounting head to dismount the bead.
3. Dismounting the sensor: Remove the cap, screw nut, and washer from the valve stem, and then remove the sensor assembly from the rim.
4. Mounting sensor and valve: Firmly connect the valve stem and the sensor body. Remove the cap, screw nut, and washer from the valve stem one by one. Slide the valve stem through the valve hole of the rim with the sensor on the inside of the rim, assemble the two parts back on the stem in the order of washer, screw nut.Tighten the screw nut with 4.0N·m with the help of the fixed rod, then assemble the cap back on the stem.
5. Mounting the tire: Place the tire on the rim, make sure that the valve faces the separation head at an angle of 180. Mount the tire over the rim.
Autel provides complete TPMS solution from diagnostics to TPMS programming. MX-Sensor can be programmed with Autel TPMS tools such as:
Note: It’s suggested to program the sensor before installation.
