Accurate Battery Results

Are you still sitting in the car and having a headache because the car won't start? what is really resons? It may be battery is dead or aging and needs to be replaced. Only invest in BT506, you can save yourself from headache, Small Invest and High Yield, why not try BT506?

What can BT506 do?

1. Battery Health Monitor: Checks cold cranking capability and battery aging status, and informs users to replace batteries before battery aging.
2. Adaptive conductance technology: Test low-capacity batteries and discharged batteries, improve the detection rate of abnormal batteries, and reduce the misjudgment rate to minimum
3. Battery Charging System Test: Judge the health of the generator by testing car charging system (12V/24V) to avoid damage to the battery due to overcharging or incomplete charging.
4. Starter System Test: first ensure that the output voltage of the generator is in a normal state, and then check whether the generator and diode can provide enough power for the vehicle start system. And further determine whether the battery can be charged normally. According to Cranking status, BT506 can quickly identify car battery charging condition.
5. In-vehicle test/ Out-vehicle test: in vehicle test is mainly on cranking and charging system; out-vehicle test is mainly for batteries that are not installed in a vehicle, like battery capacity, type, standard, etc.
6. Detection battery capacity range: CCA range 100-2000A
7. For battery types: FLOODED, AGM, AGM SPIRAL, EFB, and GEL
8. Complies with battery grade standards: CCA, SAE, CA, EN, IEC, DIN, JIS and MCA
9. Easy Operation: Easy to connect with Autel Scanner or smartphone

What makes BT506 more highly cost effective?

1. Free lifetime Updates
2. Upgrade to BT508 (buy additional V200P)
3. Wide Compatibility: Compatible with Autel wireless scanners (except MK908 MK908P)

Design for 12V and 24V Cranking/ Charging Systems

Autel BT506 battery analyzer covers 98% of the car batteries on the market and strictly implements the car evaluation standards. It is widely loved by battery testing factories and workshops. It can quickly provide customers with the most accurate results, reduce the number of retests, and reduce time costs.

• Working on 6/12V automotive batteries: 100 to 2000 CCA Range
• Working on 12- and 24- cranking/charging systems
• Battery Types: Test regular flooded, AGM,AGM spiral, GEL and EFB batteries,
• Multiple rating systems are covered:CCA, SAE, CA, EN, IEC, DIN, JIS and MCA

Advanced Adaptive conductance

What is adaptive conductance?

• Adaptive conductance testing refers to repeated tests on the same battery many times on an adaptive basis without depleting the battery.

Why bring adaptive conductance into BT506?

• This brings us to the difference between load test and adaptive conductive test. Unlike traditional load tests, which consume a large amount of amperes from the battery during the test, adaptive conductance test can quickly and accurately determine the health of the battery at almost any given state, without the need to re-test and waste additional time.

Benefit of adaptive conductive technology:

• Reduce the battery misjudgment rate to a minimum
• Improve the bad battery detection rate
• Reduce retest times
• Ensure the power of the battery under test during the test

BT506 Advanced features explore: Start Test + Charge Test + Battery Test

1. Generator Test

Generator test refers to test different parts of the charging system, including generators, rectifiers, rectifier diodes, etc., to obtain the real charging voltage value.

All battery data about ripple, no-load voltage, load voltage are displayed to customers.

2. Starter Test

Starter test help you analyze the starter motor, including start voltage and start time, to check if the starter motor is working properly.

• Load voltage refers to the voltage measured when on-board electrical appliances (such as headlamps) are turned on.
• No-load voltage is the voltage measured when all on-board electrical appliances are turned off.
• Start time is the time it takes for the vehicle to turn on the engine

3. Battery Test

After battery test is completed, SOH (state of health), SOC (state of charge), voltage, current, rating, and specific guidance and suggestions can be visually displayed, and the batteries can be clearly divided into: Good Battery; Good & Recharge; Charge & Retest; Bad Cell; Replace Battery.

Color-coded results summary, a list of test data, and repair tips helps you perform battery test in easy way.

Smartphone & Autel Scanner Compatibility

Different between traditional battery test, Autek MaxiBAS BT506 supports connect with Autel scanner and PC,which work together to perform complete battery test functions.

Steps to connect with mobile phone:

1. Install the MaxiAP200 app (Android OS download it from Google Play, IOS download it from App Store)
2. Click the MaxiAP200, register/login the Autel account.
3. Scan the QR behind the BT506 to bind the BT506 to the phone
4. Start battery scan

Steps to connect with Autel scanners:

1. Click VCI manager APP to bind the BT506 to the scanner
2. Click Battery Test App to start battery test

Upgrade to BT508, Get All BT508's Features

Just extra purchase V200P, BT506 convert to BT508 immediately, you will get more superior battery test functions as belows:

• Battery Change: Guides you to replace the battery step by step.
• Complete battery replacement proccess: Battery Type---Preparation---Replace battery---New Battery Test ---Battery Test.
• Autel BT508 offers unique battery registration guidance and one-click registration of new batteries for 53+ car brands. After the battery is replaced, some component position Settings may be lost. In this case, the electrical reset function can reset the previous data, allowing the entire vehicle electrical system to recover normal.
• All System Diagnostics: After equipped with V200P, BT508 supports all systems diagnostics for only one vehicle brand.(Optional)

Note: All above functions are BT508's features, only purchase V200P, unlock above functions.
